About Arras Energy

A simulation platform for future electricity distribution power systems.

Arras Energy, previously known as HiPAS GridLab-D, has emerged as an important open-source tool for utilities, researchers, and technology vendors in the development, maturation, and deployment of smart-grid and renewable energy resource integration technology.

Background

GridLAB-D was originally developed for the US Department of Energy by a team of researchers at Pacific Northwest National Laboratory to address emerging electric power system engineering challenges associated with grid modernization and climate change response, mitigation, and adaptation.

linux

The first release of GridLAB-D was in 2008. Since then it has been used by the US Department of Energy for key electric power system studies, including conservation voltage reduction, dynamic pricing, peer-to-peer energy exchange, and fault-induced delayed voltage recovery.

Key results:

  • Achieved 97.5% success rate in automatic conversion from Cyme models.
  • Simulation speed tests approximately 180 times faster than the DOE version.
  • Significant reductions in cloud operating costs, including 94% reduction in storage, and more than 99% reductions in runtime and computing costs.

Architecture

Arras delivers an open and developer-friendly framework for addressing important use-cases identified by key industry stakeholders. These use-cases include (1) distributed energy resource hosting capacity, (2) tariff design, (3) end-use load electrification, (4) extreme weather resilience, (5) wildfire safety and protection, (6) peer-to-peer energy, (7) advanced load modeling and forecasting, and (8) high-performance scenario planning at scale to better plan for increasing uncertainty with DER integration.

linux

Arras addresses the needs of key stakeholders such as power system researchers, planners, operators, policy-makers and regulators. Specifically, this software provides an open-source advanced power system simulation engine capable of performing very large scale simulations of distribution systems that include a large fraction of so-called smart grid technology and distributed energy resources that the key stakeholders cannot obtain and/or afford to license from existing software vendors. The goal is for these open source tools to continue to gain ongoing support to possibly open the idea of replacing legacy license tools.

Energy Efficiency

In 2018, the California Energy Commission authorized $6M of EPIC program funding for three open-source projects for SLAC National Accelerator Laboratory to create a commercially viable version of GridLAB-D’s back-end simulation engine and Hitachi America Labs to create a front-end for users in California’s three largest utilities. This push for electrical efficiency include all users for the tool, from students, researchers, utilities (investor owned and publicly owned), regulators, developers, etc. The front-end software is called GLOW (which stands for GridLAB-D Open Workspace), and the back-end software, which was called HiPAS GridLAB-D, now Arras, as well as OpenFIDO which includes the pipeline tools that use Arras for multifunctional purposes.

Learn More

Check out the Tutorials for more quick access to learning materials. Learn about the sucess stories of Arras Energy’s implentation for Use-Cases. Read into in-depth literature and news articles at Reports.

Authors

Chassin, David P., Alyona I. Teyber, Elizabeth Buechler, Duncan Ragsdale, Matthew Tisdale. 2023. HiPAS GridLAB-D: High-Performance Agent-based Simulation with GridLAB-D. California Energy Commission. Publication Number: CEC-500-202X-XXX.
